DNAKE IPK02 IP65 Surface Mounted IP Intercom Kit with 7-inch TFT LCD Indoor Monitor

Click Image for Gallery

Description
Specification

Embrace security with a simple touch. DNAKE IP Video Intercom kit is a complete solution that includes a door station, an indoor monitor, and accessories to mount. The new IP intercom kit is immediately ready for use and does not require any special programming. Improve your safety at home while increasing convenience with the DNAKE IP Video Intercom Kit!

**Please note, Dnake Smart Life App only supports 1 x relay output with E216 Monitor. Please enquire for other options that require the app to operate more than one output.

Kit Features

Plug & Play
User-friendly interface
Standard PoE
One-touch calling
Remote Unlocking and support PIN Code
CCTV integration

S213K Intercom Features

Powered by PoE or power adapter (DC12V/2A)
Support IC (13.56MHz) & ID (125kHz) card, PIN code
3 Indicator Lights
2 relays supported
Tamper alarm
Keypad supported

E216 Monitor Features

Easy configuration
7-inch capacitive touchscreen
Powered by PoE or power adapter (DC12V/2A)
Support SIP 2.0 protocol, easy integration with other SIP devices
Easy integration witH elevator control systems
Support monitoring 8 IP cameras
Supports 2 x relay outputs

Package Contents

DNAKE S213K (Power adapter not included)
Bracket
Screwing Kit
User Manual

Datasheets

Details
Access Control Equipment	Intercom: IC (13.56MHz) & ID (125kHz) card, PIN code
Indications	Intercom: Indicator lights = 3
Materials / Finish	Intercom: Aluminium Monitor: Plastic
Mounting Type	Intercom: Surface Monitor: Surface / Desktop
Reset Button	Intercom: Yes
System	Linux
Vandal Resistance	Intercom: IK08
Dimensions
Dimensions (mm)	Intercom: 188 x 88 x 34 Monitor: 195 x 130 x 14.5
Drive
Rated Load	Intercom: 3.5W Monitor: 9 W
Electrical Data
Audio	Audio Codec: G.711 Echo Cancellation DTMF: RFC2833 Microphone: Built-in microphone Speaker: Built-in speaker
Power	Monitor: Output: 1 (12V / 100mA)
Power Supply	PoE (802.3af) or DC 12V/2A
Stand-by Power	Intercom / Monitor: 1.5 W
Angle of view (H x V - °)	60º x 125º
Camera Resolution	2MB, CMOS
On-Screen Display (OSD)	Monitor: Display: 7-inch TFT LCD Screen: Capacitive touch screen Resolution: 1024 x 600
Video Codec	H.264
Video Resolution	1280 x 720 ~ 25fps
Lighting Specifications
Lighting Type	LED White Light Compensation
Memory
Memory	RAM: 64 MB ROM: 128 MB
Network
Ethernet Port	Intercom: 1 x RJ45 10/100 Mbps adaptive Monitor: 1 x RJ45 10/100 Mbps adaptive
Protocols	ONVIF, SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP
Optics and Sensors
Angle of View	110º
Performance Data
Working Humidity	Intercom: 0% to 90% (non-condensing) Monitor: 10% to 90% (non-condensing)
Working Temperature	Intercom: -40ºC ~ +55ºC Monitor: -10ºC ~ +55ºC
Safety Relay Data
Input	Intercom: Relay In = 2 Monitor: Doorbell Input: 8 (use any alarm input port) Alarm Input: 8
Technical
IP Rating	Intercom: IP65
Relay Outputs	Intercom: 2
Wiegand Input	Support
