- Recommended to defluctuate power spikes and troughs, help protect control boards etc.
- Screw on mounting chassis, from top.
- Quick connect 6.3 x 0.8 mm terminals.
- Designed specifically for standard applications.
- Protects against interference voltage from the mains.
| Mains Filter Stats | |
| Cx (X2) [nF] | 68 |
| Cy (Y2) [nF] | 2.2 |
| Housing | 41 |
| L [mH] | 2 x 0.3 |
| Leakage Current [mA] | 0.25 mA |
| Rated Current [A] | 10A |
| Performance Data | |
| Working Temp. (°C Min/Max) | -25 to 100°C |
