Visible, reliable security at your fingertips
Know who’s knocking, from the indoor touchscreen monitor or via your EZVIZ App. With simple taps on the big or small screen, you can see every detail with clear video quality. You can also set the ringtone as you like and talk to your visitors with ease. Protection is made simple with activity-triggered alerts, so you don’t miss a moment.
A useful touch screen made for everyone – The large and colourful touchscreen monitor is extremely easy use, even for the elderly and children. No more need to lean against the door to look through the tiny peephole. You will know who’s outside by pressing the home button. The screen can also be set to automatically turn on upon detection of visitors.
Get the whole picture in front of your door in Full HD – The DP2 helps reduce blind spots with a wide 166-degree visual coverage, and captures details in sharp 1080p.
Greet every visitor with calm and ease – Working as a peephole camera and a doorbell, the DP2 ensures both security and convenience. Know instantly who is at your door, why and how to handle the situation even you are far away from home. There is even a voice changer if you’d prefer to remain unidentifiable to a stranger.
Smarter detection tells you what you want to know – Integrating PIR motion detection with human shape detection, the DP2 is designed to reduce false alarms caused by trivial moving objects. Whether you live near a busy street or in a quiet neighborhood, you can customize the detection sensitivity to receive alerts that you care about.
Wire-free protection with 3-month battery life – The DP2 features a 4,600 mAh rechargeable lithium battery. The standby time can reach up to 90 days* with the smart power-saving functionality
Built to last – Made with high-endurance zinc alloy, the DP2 is both sturdy enough for the outdoors and stylish enough to fit your front-door style.
Safe, flexible storage options – Save videos locally on a 256 GB storage card, which can be inserted onto the indoor monitor. This guarantees data security in case the outdoor camera is damaged. Or, if you prefer, subscribe to EZVIZ CloudPlay for fully encrypted cloud storage.
* Data from EZVIZ’s lab results, based on the usage of 5 minutes per day under standard conditions.
What’s in the box
- DP2 Peephole Doorbell
- Panel
- Mounting Base
- Buckle
- Screws x 6
- Power cable
- Regulatory Information
- Quick Start Guide
General Specifications
Screen: 4.3 inch Color Touch Screen
Color: Silver
Button: Doorbell button, power button, screen wake-up button
Supported Peephole Diameter: 16.5 mm to 50 mm (0.65 inch to 1.97 inch)
Supported Door Thickness: 35 mm to 105 mm (1.38 inch to 4.13 inch)
Detection: Advanced PIR Motion Detection
PIR Angle: 110°
PIR Distance: Up to 20 ft / 6 m
PIR Sensitivity: Adjustable
Image distortion correction: Supports
Local Storage: Supports microSD card (Up to 256 GB)
Cloud Storage: Supports EZVIZ CloudPlay storage (Subscription required)
General Function: Cloud video encryption and image encryption
Network Specifications
Protocol: EZVIZ Cloud Proprietary Protocol
Video Intercom: Local and remote video intercom
Wi-Fi Standard: IEEE802.11b, 802.11g, 802.11n
Frequency Range: 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth: Supports 20 MHz
Security: 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK, WPS
Transmission Rate: 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps
Audio / Video
Sensor: 1/2.7″ Progressive Scan CMOS
Lens: 2.0mm @ F2.0
Viewing angle: 166° (Diagonal), 136° (Horizontal), 80° (Vertical)
Max. Resolution: 1080p / 2MP
Day / Night Switch: ICR infrared filter
IR Night Vision Distance: Up to 16.4 ft / 5 m
Video Frame Rate: 15 fps
WDR: DWDR
Audio Input: Built-in high sensitivity microphone
Audio Output: Built-in high-power speaker
Ringtones: Supports up to 5 ringtones, and the volume is adjustable
