The LiftMaster ART300K 230v double articulated gate opener kit is part of the ART series. The motors in this kit can support gates up to 3.5m in length, and with a shorter gate length (2.5m), it can sustain gates weighing up to 300kg.
This unique articulated arm kit is perfect for tall pillars. This operator has an automated stop and a built-in limit switch as distinctive features.
Features
- Symmetrical and compact design
- Automatic stop
- Built-in limit switch Open/Close
- Manual release in case of power outage
- Mounting brackets for wide pillars included
- Maintenance free
- Rotation distances possible up to 30cm
- Robust construction
- Can be used for folding doors
Kit Includes:
- 1 x Control Panel
- 2 x TX4UNIS Remotes
- 1 x Pair of 772E Photocells
- 2 x Electro Mechanical arms
- 1 x Key switch
Manuals & Datasheets
| Electrical Data | |
| Absorption (A) | 1.8 |
| Motor Voltage | 230v |
| Power (W) | 400 |
| Gate Specifications | |
| Automation Type | Articulated |
| Kit Type | Double |
| Max. Gate Leaf Length (M) | 3 |
| Max. Gate Weight (KG) | 250 |
| Performance Data | |
| Speed (RPM) | 1400 |
| Torque (N) | 350 |
| Work Cycle (cycles/hour) | 20 |
| Working Temp. (°C Min/Max) | °C -20/+55 |
| Technical | |
| Protection Level (IP) | IP44 |
LiftMaster ART300K Articulated Gate Opener - Double Kit
- Brand: LiftMaster
- Product Code: ART300K
- Availability: Discontinued
